Straight Seam Welding Machine
This machine is used to weld straight seam of pressurized solar water heater inner tank.
Max. Welding Thickness: 2.0mm
Max. Effective Length: 2500mm
Air Pressure: 0.5-0.8mpa
Power: 6.0kw
8 Hours Max. Efficiency: 120 pcs inner tanks
Automatic Flaring Machine
This machine is used for flaring two ends of inner tanks.
Material: SPCC, Stainless Steel
Thickness: SPCC 2.5mm, stainless steel 2.0mm
Diameter: 280mm- 450mm
Length: 280-1400mm
Automatic Inward-bending Machine
This machine is used for processing two ends of electric water heater outer tanks.
Tank Thickness: 0.4-0.8mm
Tank Material： Stainless steel, SPCC, PPGI
Efficiency: 3-5pcs/min
Sand-blasting Line
This line is used for sand-blasting of inner tanks.
Material: SPCC, Stainless Steel
Thickness: 1.5~2.0mm
Diameter: Ø300- Ø480
Length: 350-1400mm
Power Consumption: ≤28kw/set
Gas Supply Pressure: 0.5-0.7Mpa
Foaming Line
This line is used for foaming of inner tanks.
Diameter: About φ600
Length: Below 1700mm
Plat-chain Dimension（L×B×H）: 650×100×2
Environment Temperature: 22℃～30℃
Foaming Temperature: 24℃±3℃
